TEBAK JY-19 Wood CNC Router Engraver Industrial Engraving Machine 6040 1.5kw 2.2kw Milling Machine
TEBAK JY-19 Wood CNC Router Engraver Industrial Engraving Machine 6040 1.5kw 2.2kw Milling Machine
Couldn't load pickup availability
TEBAK JY-19 CNC Router Engraver Industrial engraving machine 6040 Milling Machine
| MODEL |
CNC 6040 router |
|||
| Attribute |
1.5KW 3axis |
1.5KW 4axis |
2.2KW 3axis |
2.2KW 4axis |
| Axis |
3axis |
4axis |
3axis |
4axis |
| Limit switch |
Yes |
Yes |
Yes |
Yes |
| With hand wheel |
Yes |
Yes |
Yes |
Yes |
| Spindle motor |
1.5KW |
1.5KW |
2.2KW |
2.2KW |
| Weigh |
85 |
95 |
88 |
98 |
| Machine Dimensions |
860X660X590mm |
|||
| Rack material |
6061 Hard aluminum alloy |
|||
| Engraving area |
XYZ: 600*400*100mm |
|||
| Acceptable material thickness |
≤ 150mm |
|||
| Driving core |
XYZ: TBI 1605 ball screws |
|||
| Sliding core |
XYZ: Diameter 20*20*16mm |
|||
| Limit switch |
XYZ: each 2 Photoelectric limit switch |
|||
| Spindle motor |
VFD water-cooled spindle , 0-24000r/min |
|||
| Collet type |
1.5KW-ER11,2.2KW-ER20 (3.175mm) Collet |
|||
| Stepper motor and drive |
two-phase hybrid stepping motor 57 3A 1.8 Degree |
|||
| Maximum operating speed |
4000mm/min (Engraving speed: 300-3000mm/min) |
|||
| Positioning Accuracy |
0.05mm |
|||
| Repeatability precision |
0.01-0.02mm |
|||
| Communication interface |
Parallel Port (mach3 control) |
|||
| System requirements |
Win-XP or win-7 8 10(32) operating system |
|||
| Software Compatability |
Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam) |
|||
| Command code |
G code/.nc/.ncc/.tab/.txt |
|||
| Rotation Axis (4th Axis) Description |
Center height: H = 65mm Maximum turning diameter: ≤ 120mm Deceleration ratio: 6:1 Stepper motor: 57-3A-1.8 Weight: 7.5KG |
|||
