A Vertical Drilling Tapping Machine New Mechanical Hardware Bench Drill, Tapping Machine, Milling Machine CNC Drilling Machine
A Vertical Drilling Tapping Machine New Mechanical Hardware Bench Drill, Tapping Machine, Milling Machine CNC Drilling Machine
Regular price
$1.00 USD
Regular price
$99.00 USD
Sale price
$1.00 USD
Unit price
per
Couldn't load pickup availability
Products Description
Machine Feature:
1.High efficiency motor, strong power and long service life.
2.Belt drive greatly reduces noise
3.Aluminum alloy hard belt disk,good balance, small shaking
4.Fine grinding worktable, machining accuracy is higher
1.High efficiency motor, strong power and long service life.
2.Belt drive greatly reduces noise
3.Aluminum alloy hard belt disk,good balance, small shaking
4.Fine grinding worktable, machining accuracy is higher
5.Heavy cast iron for good stability
Machine Parameter
|
Maximum drilling diameter(mm)
|
16
|
|
Diameter of column(mm)
|
59
|
|
Maximum stroke of spindle(mm)
|
80
|
|
Distance from spindle center to coloum (mm)
|
190
|
|
Maximum distance from spindle end to table(mm)
|
260
|
|
Maximum distance from spindle end to base table(mm)
|
360
|
|
Spindle taper
|
B16
|
|
Spindle speeds range(r/min)
|
448/883/1588/2988
|
|
Spindle speed series(mm)
|
4
|
|
Table size(mm)
|
190x190
|
|
Base size(mm)
|
260x360
|
|
Total height(mm)
|
755
|
|
Motor(w)
|
550W
|
|
Netweight(kg)
|
35
|
Packing & Delivery
Packing:
Machine packing inside is plastic films and outside is fumigation wooden case.
Our wooden case is very strong,it can bear long time shipping on the sea.
And machine with preservative film, it can stop the salt sea water enter into the machine and make the machine corrosion.
Our wooden case is very strong,it can bear long time shipping on the sea.
And machine with preservative film, it can stop the salt sea water enter into the machine and make the machine corrosion.
Delivery:
For machines are big and heavy parcel, and different country with different delivery cost,so we suggest below delivery solution:
1. Over 1CBM or 100KG, we suggest send by Sea.
2. Below 1CBM or 100KG, we suggest send by Air.
3. Below 0.5CBM or 50KG, we suggest send by Express.
The price show on our website just the machine EXW price, please contact us for confirm delivery cost before you place order.
1. Over 1CBM or 100KG, we suggest send by Sea.
2. Below 1CBM or 100KG, we suggest send by Air.
3. Below 0.5CBM or 50KG, we suggest send by Express.
The price show on our website just the machine EXW price, please contact us for confirm delivery cost before you place order.
Company Profile
Hengshui Mengshang Trading Co., Ltd. is a main professional supplier in Product Machine,CNC Carbide inserts, Turning tools and
Milling tools, Our brand is TEBAK, Design and Sales. We insists the principles of "High quality, Competitive price and Excellent
service."We are leading OED&ODM manufacture many years of experience in this filed. TEBAK have various kinds of productc and they
are 70% for expert. Our customers are from all over the world, such as North America, Europe, South America, the Middle east, East
Asia and Africa. The quality control standards are based on ISO9001 certifications. TEBAK relies on advanced automatic machining
center and complete testing testing method, control all aspects of production and operation according to the standard process. We
have an outstanding team of designers to continuously launch innovative product design, in order to meet the needs of the
international marked. Welcome send inquiry to us, we will provide high quality products and excellent service for you!
Milling tools, Our brand is TEBAK, Design and Sales. We insists the principles of "High quality, Competitive price and Excellent
service."We are leading OED&ODM manufacture many years of experience in this filed. TEBAK have various kinds of productc and they
are 70% for expert. Our customers are from all over the world, such as North America, Europe, South America, the Middle east, East
Asia and Africa. The quality control standards are based on ISO9001 certifications. TEBAK relies on advanced automatic machining
center and complete testing testing method, control all aspects of production and operation according to the standard process. We
have an outstanding team of designers to continuously launch innovative product design, in order to meet the needs of the
international marked. Welcome send inquiry to us, we will provide high quality products and excellent service for you!
